Surface Mount Chokes - SSQ12N-U series from K-Well
Switched mode power supply uses a common mode choke on the AC power line to mitigate Electromagnetic interference. Traditionally through hole components have been used, which required a lengthy and expensive manual assembly process.
To enable a fully automated assembly and more cost-efficient process, Kormag is pleased to introduce the SSQ12N-U series from K-Well, which offers popular values such as 15mH with a 1.2A max value. With dimensions of 18mm x 17mm x 9mm, we have a compact footprint using a SMD package, with flat wire windings.
High permeability materials deliver a high impedance to both common and differential mode noise with flat wire winding reducing power losses. This range of parts can be used in SMPS topologies like Flyback, Forward and PFC boost converters with a power rating ranging from 20 watts to 120 watts.
For datasheets, click the button below!
